800mm Linear Rail Assembly - MGN15 Rail + 1610 Ballscrew + Nema23 Stepper

Pre-assembled linear motion module - great for quick set up. Perfect for CNC machines / precision linear motion tasks.

Specs:

• Total assembly length = 400mm
• 1610 Steel Ballscrew & bearing
• MGN12 linear rail & bearing
• Diaphragm coupler and ball screw bearings installed.
• Nema 3.0A 57/56 stepper motor - 4 lead wires, 1.8deg step angle, 2.85 rated voltage
• Assembly accuracy +/- 0.05mm
• Load capacity - 30kg on flat, 15kg vertically.
• Aluminum base frame with drop in T nuts inserted.
